Supporting Platforms

• NVIDIA Quadro® Plex officially certified system or platform
• Microsoft® Windows® XP (64-bit and 32-bit)
• Microsoft Windows 2000 (32-bit)
• Linux® - Full OpenGL® implementation, complete with NVIDIA and ARB extensions (64-bit and 32-bit)
• Solaris x86

NVIDIA Quadro GPU Architecture

• 128-bit color precision (IEEE fp32 bit per component)
• 3D volumetric texture support
• Fully programmable GPU (OpenGL2.1/DirectX 10.0)
• Shader Model 4.0 (Model IV only & S4)
• C Programming Environment (Model IV & S4 only)

Display Resolution Support (Model I, II, III, & IV only)

• Analog displays up to 2560 x 1600 @ 60Hz
• Dual-link DVI-I outputs - drive digital displays at resolutions up to 2560 x 1600 @ 60Hz
• Native support for Sony 4K SXRD™ large venue projector

Product Details

• Quadro Plex Deskside VCS (Model I, II, III, IV)
  • Quiet operation (40dB) suitable for office environment
  • Connects to host via cabling to a low power PCI Express x8 or x16 adapter card
  • Optional rack mount kit

• Quadro Plex Rack Mount Graphics Server (Model S4)
  • Standard 19”, 1U rack-mount chassis
  • Connects to host via cabling to a low power PCI Express x8 or x16 adapter card
  • Standard configuration: 1 PCI Express connector driving 4 GPUs
  • Optional configuration: 2 PCI Express connectors driving 2GPUs each

SDI Modes (Model lll only)

• Transparent Mode – work with any existing application using clone and dualview modes
  • 2 channel fill
  • 8-bit
    • RGB    4:4:4
    • YCrCb    4:2:2 or 4:4:4
• Extended Mode – integrate into applications using NVIDIA SDI API
  • 4 channel fill or 2 channel fill + 2 channel key
  • 8-, 10-, 12-bit
    • RGB    4:4:4
    • YCrCb    4:2:2 or 4:4:4
    • 2x YCrCb    4:2:2 + 4:2:2
    • YCrCbA    4:2:2:4
    • RGBA    4:4:4:4 (8-bit only)

*Available only on Models IV and S4
