The NVIDIA Quadro Plex is designed to interface with industry-standard workstations and servers to deliver advanced visual computing scalability for the most demanding professional applications.

Available in three distinct models NVIDIA Quadro® Plex is architected to meet your specific application requirements.

System Requirements

	Model ll Four NVIDIA Quadro FX 4500 GPUs Two NVIDIA Quadro G-sync boards Up to 8 channels 32X SLI FSAA (max on single channel)
	Model lV Two NVIDIA Quadro FX 5600 GPUs One NVIDIA Quadro G-Sync board Up to 4 Channels 64X SLI FSAA (max on single channel)
	Model S4 Remote Graphics System Four NVIDIA Quadro FX 5600 GPUs 1U Server Form Factor

NVIDIA Quadro Plex
	Model ll	Model lV	Model S4
GPU	NVIDIA Quadro FX 4500	NVIDIA Quadro FX 5600	NVIDIA Quadro FX 5600
Total GPUs	4	2	4
Total Frame Buffer	2GB (512MB/GPU)	3GB (1.5GB/GPU)	6GB (1.5GB/GPU)
Option	Quadro G-Sync	Quadro G-Sync II	N/A
Channels	8 dual-link DVI	4 dual-link DVI	N/A - high performance readback to host
Key Features
C Programming Environment	N	Y	Y
Shader Model	3.0	4.0	4.0
Genlock/frame lock	Y	Y	N/A
Frame Synchronization	Y	Y	N/A
HD SDI	N	N	N/A
FSAA (Max per Channel)	64x SLI FSAA	64x SLI FSAA	32xFSAA
Product Specifications
USB	2 Front		N/A
Host Connection	PCI Express x16 or x8**, Small Form Factor, Passive (10W) 2M (6.5 foot) NVIDIA Quadro Plex Interconnect Cable
Power	480W		900W
	110/240 VAC autosensing worldwide power supply
Accoustics	40dB		~70dB
Form Factor	Tower Desktop (9.49" H x 5.94" W x 20.55" D) or Rack Mount (3U H x 8.5" W x 20.55" D)		1U Rack Mount (1.75"H x 17.4"W x 31.0" D)
Weight*	18.6lb	19.8lb	~40.0lb

Maximum # of Quadro Plex per host = 2

*Standalone weight

** Requires optional x8 interface card
