Features Benefits

Uncompressed 8-, 10-, or 12-Bit SDI Output
Enables on-air broadcast, video production and post production professionals to composite and output live video and graphics to true, uncompressed 12-bit SDI in 2K, SD, or HD resolutions and allows direct connection to a broadcast monitor, switcher, tape deck, or SDI projector.

Ancillary Data Support
Support for ancillary data through an NVIDIA API. Support for the introduction of ancillary data into the out going SDI video is provided through an NVIDIA API. This ancillary data can include up to 16 channels of embedded 24-bit digital audio as defined by SMPTE 272M and SMPTE 299M as well as timecode.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

2D Video Pass Through Compositing
2D Video Compositing enables incoming video to be passed through and alpha composited, luma keyed, or chroma keyed with the Quadro rendered graphics image on the outgoing SDI video.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

Genlock (House Synchronization)
One genlock (Standard BNC) connector (digital or analog) provides connectivity to a video sync source for SMPTE standard (digital, black burst, tri-level) synchronization. Expanded cross sync functionality permits an incoming house signal to synchronize a much larger number of video output signal formats.

Flicker Filter
The Quadro GPU includes a built-in flicker filter for the high quality rendering of computer graphics images in interlaced formats.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

Rotated-Grid Full-Scene Antialiasing (RG FSAA)
The rotated grid FSAA sampling algorithm introduces far greater sophistication in the sampling pattern, significantly increasing color accuracy and visual quality for edges and lines, reducing “jaggies” while maintaining performance.

512MB to 1.5GB Ultra-Fast Graphics Frame Buffer Memory
Delivers high throughput for interactive visualization of large models and high-performance for real time processing of large textures and frames and enables the highest quality and resolution full-scene antialiasing (FSAA).
*Available on NVIDIA Quadro FX 5600 SDI and FX 4600 SDI

8K Texture and Render Processing
The ability to texture from and render to 8K x 8K surfaces. Beneficial for applications that demand the highest resolution and quality image processing.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

Fast 3D Texture Transfer
Fast transfer and manipulation of 3D textures resulting in more interactive visualization of large volumetric dataset.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

Next-Generation Vertex and Pixel Programmability Shader Model 4.0
Reference standard for Shader Model 4.0 enabling a higher level of performance and ultra-realistic effects for OpenGL and next generation DirectX 10 industry-leading professional applications.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

NVIDIA GPU Unified Architecture
Industry’s first unified architecture designed to dynamically allocate compute, geometry, shading and pixel processing power to deliver optimized GPU performance. The NVIDIA UDA guarantees forward and backward compatibility with software drivers. Simplifies upgrading to a new NVIDIA product because all NVIDIA products work with the same driver software.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

128-Bit Precision Graphics Pipeline
Enables sophisticated mathematical computations to maintain high accuracy, resulting in unmatched visual quality. Full IEEE 32-bit floating-point precision per color component (RGBA) delivers millions of color variations with the broadest dynamic range.

High Bandwidth GPU Memory
GPU memory acts as high performance level two cache enabling blistering data transfer to and from the GPU for operations such as, rendering, shading, and texturing, and general purpose computation. Supports the world’s fastest graphics memory with lower power consumption than previous generation systems.

32-Bit Floating Point Precision for Filtering and Blending
Sets new standards for image clarity and quality through 32-bit floating point capabilities in shading, filtering, texturing, and blending. Enables unprecedented rendered image quality for visual effects processing.

Advanced Color Compression, Early Z-Cull
Improved pipeline color compression and early z-culling to increase effective bandwidth and improve rendering efficiency and performance.

Cg High-Level Graphics Shader Language
Cg—“C” for graphics—is a high-level, open-standard programming language that takes advantage of the power of programmable GPUs. NVIDIA Quadro FX programmable graphics pipelines leverage high-level shading languages to enable the creation and integration of real-time photorealistic effects into 3D models, scenes, and designs. This represents a key enabler for the creation of real-time, photo-realistic visuals within CAD, DCC, and scientific applications.

GPU Computing
NVIDIA CUDA provides a C language environment and tool suite in combination with high performance visualization unleashes new capabilities to solve highly complex challenges such as real-time ray tracing and interactive volume rendering.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

NVIDIA Graphics API Extensions
NVIDIA provides a set of extensions to standard graphics APIs for Linux and Windows, enabling applications to take maximum advantage of state-of-the-art GPU capabilities.

Hardware 3D Window Clipping
Hardware accelerated clip regions (data transfer mechanism between a window and the frame buffer) improve overall graphics performance by increasing transfer speed between color buffer and frame buffer.

Hardware-Accelerated Pixel Read-Back
Up to 2.4GBps pixel read-back performance delivers massive host throughput.

Highest Workstation Application Performance
Next-generation architecture enables over 2x improvement in geometry and fill rates with the industry’s highest performance for professional CAD, DCC, and scientific applications.

High-Performance Display Outputs
400 MHz RAMDACs and up to two dual-link DVI digital connectors drive the highest resolution digital displays available on the market.

NVIDIA High Precision High Dynamic Range (HDR) Technology
Sets new standards for image clarity and quality through floating point capabilities in shading, filtering, texturing, and blending. Enables unprecedented rendered image quality for visual effects processing.

NVIDIA PureVideo HD Technology
The ultimate high-definition movie experience on your PC by combining high-definition movie decode acceleration and post-processing on HDCP enabled platform, HDCP circuitry, and integration with HD movie players. It delivers superb picture quality for all video formats, as well as stunning HD DVD and Blu-ray movies—with low CPU utilization and power consumption.

PCI Express Certified
PCI Express is an Intel bus architecture that doubles the bandwidth of the AGP 8X bus, delivering greater than 2 GBps in both upstream and downstream data transfers.

Single Dual-Link Digital Display Connector
Dual-link TMDS transmitter supports ultra-high-resolution panels (up to 3840 x 2400 @24Hz) --which result in amazing image quality producing detailed photorealistic images.

Ultra quiet design
Accoustics lower than most desktops at sub 40dB for a quiet desktop environment.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

Compatible with Industry Standard Architectures
Compatible with x86 32 and 64-bit microprocessor architectures and operating systems from Intel/AMD and Microsoft/Linux.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI

Unmatched Color Precision
Full 128-bit precision graphics pipeline enables sophisticated mathematical computations to maintain high accuracy, resulting in unmatched visual quality. Full IEEE 32-bit floating-point precision per color component (RGBA) delivers millions of color variations with the broadest dynamic range.
*Available on NVIDIA Quadro FX 5600 SDI and 4600 SDI
