Technical Specifications

NVIDA GPU motherboard solutions are the platform for a wide range of flexible, affordable PC designs with features appropriate for stable image, media, home/SOHO, and business applications in traditional and new form factors that fit the style and budget of today's PC users. Compare and choose the GPU Motherboard that fits your needs:

NVIDIA Quadro NVS 210S and NVIDIA nForce 430 NVIDIA GeForce
6150 and NVIDIA nForce 430
NVIDIA GeForce 6150 LE NVIDIA nForce 430 NVIDIA GeForce 6150 SE NVIDIA nForce 430 *NVIDIA GeForce
6100 and NVIDIA nForce 430
NVIDIA GeForce
6100 and NVIDIA nForce 410
NVIDIA GeForce
6100 and NVIDIA nForce 405
NVIDIA GeForce
6100 and NVIDIA nForce 400
CPU AMD Commercial Stable Image Platform Qualified Athlon 64 Sempron Athlon 64 Sempron Athlon 64 Sempron Athlon 64 Sempron Athlon 64 Sempron Athlon 64 Sempron Athlon 64 Sempron
Supported Sockets 939, AM2 939, 754, AM2 939, 754, AM2 939, 754, AM2 939, 754, AM2 939, 754, AM2 939, 754, AM2 939, 754, AM2
NVIDIA PureVideo
DirectX 9.0 Shader Model 3.0 Support
TV Encoder sDVO -> TV sDVO -> TV
TMDS/DVI sDVO -> TV sDVO -> TV
Graphics Clock 425 MHz 475 MHz 425 MHz 425 MHz 425 MHz 425 MHz 425 MHz 425 MHz
PCI-Express 1x16
2x1
1x16
2x1
1x16
2x1
1x16
2x1
1x16
1x1
1x16
1x1
1x8
2x1
2x1
HD Video Playback
SD Video Playback
Audio HDA (Azalia) / AC97 HDA (Azalia) / AC97 HDA (Azalia) / AC97 HDA (Azalia) / AC97 HDA (Azalia) HDA (Azalia) / AC97 HDA (Azalia) HDA (Azalia)
Video Scaling High Quality (5x4) High Quality (5x4) High Quality (5x4) Basic (2x2) Basic (2x2) Basic (2x2) Basic (2x2) Basic (2x2)
SATA/PATA drives 4/4 4/4 4/4 2/4 4/4 2/4 2/2 2/2
SATA speed 3Gb/s 3Gb/s 3Gb/s 3Gb/s 3Gb/s 3Gb/s 3Gb/s 3Gb/s
RAID 0,1,0+1,5 0,1,0+1,5 0,1,0+1,5 0,1,0+1,5 0,1,0+1,5 0,1 0,1 0,1
NVIDIA MediaShield storage technology
Ethernet 10/100/1000 10/100/1000 10/100/1000 10/100/1000 10/100/1000 10/100 10/100 10/100
USB ports 8 8 8 10 10 8 8 8
NVIDIA nTune Utility

* Specs for the combination of GeForce 6100/nForce 430 prior to August 2006
** Specs for the combination of GeForce 6100/nForce 430 after to August 2006
