The NVIDIA® Quadro® Plex 2200 S4, ultra-dense remote and distributed graphics visualization solution, enables breakthrough levels of capability and productivity.

NVIDIA® Quadro® Plex 2200 S4 dedicated visual computing system (VCS) delivers remote and distributed graphics visualization for breakthrough levels of capability and productivity. Architected with four Quadro FX 5800 GPUs, the Quadro Plex 2200 S4 enables graphics-intensive, high-density visual computing and scales to meet the most demanding professional applications requirements.

Unprecedented levels of visual compute density
Four Quadro FX 5800 GPUs in a single 1U form factor delivers the highest density rendering solution for rack mount environments.

Revolutionary CUDA parallel computing processor for high performance visualization
Featuring 960 CUDA parallel processing cores (240 cores per GPU) for high performance visualization. Delivers up to 270x gains in performance on applications that can be written to leverage the parallel architecture of the GPU exposed through a C language environment and tool suite.

Breakthrough Performance for all leading visualization applications
Certified on industry leading CAD, DCC, scientific, and visualization applications

Advanced remote and distributed visualization solutions
Efficient remote graphics serving capabilities and scales GPU resources for offline rendering


Breakthrough Visual Compute Density
Unmatched graphics compute per cubic centimeter provides highest visual compute density enabling breakthrough levels of capability and productivity.

High Speed, PCI Express Data Transfer
With low latency and high bandwidth, computing applications benefit from the highest data transfer rate possible through standard PCI-Express x16 and x8 architecture.

NVIDIA Unified GPU Architecture
Industry’s first unified architecture designed to dynamically allocate compute, geometry, shading and pixel processing power to deliver optimized GPU performance.

NVIDIA® Quadro® Unified Memory Architecture
Allows for superior memory management, which efficiently allocates and shares memory resources between concurrent graphics windows and applications.

Standard 1U Server Form Factor
Industry standard form factor optimized for large scale server deployments. Four Quadro GPUs in a high density 1U chassis offer the highest performance for remote graphics applications. Performance optimized and power optimized products cover the range of IT server room requirements. System monitoring, thermal control and fault notification in the 1U server product provide the necessary features for efficient integration of the Quadro Plex Model S4 servers into the data center.

16 GB Total Frame Buffer - 4 GB per GPU
Delivers high throughput for interactive visualization of large models and high-performance for real time processing of large textures and frames and enables the highest quality and resolution full-scene antialiasing (FSAA).

Processor Cores 960 (240 per GPU)
Memory Size Total 16 GB (4 GB per GPU)
Shader Model 4.0
NVIDIA CUDA checkmark.gif
Platform Form factor 1U Server
OpenGL 2.1
Direct X 10
NVIDIA Quadro GPU Quadro FX 5800
# NVIDIA Quadro GPUs 4
Acoustics 66 dB
